K-QE series | Once Through Boiler

Boiler efficiency is pushedeven further in the high efficiency, low fuel cost economy boiler, Realizes an ultra high efficiency
of 97%(K-500QE) with the economizer equipped and Realizes space saving

  • Water to Steam in 5 minutes.
  • Fuel: Natural gas, LP gas
  • Equivalent evaporation: 100 ~ 500 kg / h
  • Maximum operating pressure
    0.7 MPa-[G] (K-100Q)
    0.98 MPa-[G] (K-100Q other than)
  • Boiler efficiency: 90% 91% 97%

Functions and features

  • Easy to handle because it is microcomputer
    easy-driving operation
    always shows the state and operation
    automatic stop If a problem occurs, event
    status and water level, the flame can be seen immediately
  • (13A-fired gas) Low NOx • cleanliness up in terms of combustion
  • Low noise
  • Economy boilers high efficiency and low fuel consumption
  • Space-saving design which does not take the place
  • High performance steam-water separator equipment
  • Function pursuit microcomputer control standard
